MS 3816
Chisel Mortiser 370 watt single phase has a drill chuck capacity of 3-13mm and a table size of 180*120mm
A mortise machine is essentially a specialized drill press that combines an auger with a hollow chisel to bore square holes. The auger removes most of the waste, while the chisel edges shear off the remaining material on the sides of the cut. With the relatively inexpensive MS3816 mortising machine you can create accurate mortise joints with minimal effort. Unwanted movement of the stock is eliminated by the rigid fence and hold down clamp, lateral movement of the stock whilst in the clamp is achieved via a lever operated hand wheel. The all-steel quick-adjust depth stop is easy to set and provides a positive stop. Quick access to the 13mm drill chuck is gained by unclipping the plastic cover plates located in the machines body either side of the chuck. Other features such as the large base and twin hardened and ground columns will ensure perfect mortises every time.
| Specification | |
| Chisel Capacity | 6-16mm(1/4" -5/8") |
| Max.Mortising Depth | 76mm(3") |
| Drill Chuck Capacity | 13mm |
| Max.Clamping Width | 80mm |
| Travel in Front And Behind | 40mm |
| Travel in Left and Right | 100mm |
| Spindle to Fence (max.) | 50mm |
| Chisel to Table (max.) | 100mm |
| Over Height | 800mm |
| Motor | 370w |
| Spindle speed | 1400rpm |
| Table size | 180x120mm |
| Fence Size | 180x50mm |
| Base Size | 320x270mm |
| G.W./N.W.: | 46/42kgs |
| Packing Size | 630x420x340mm |
